Merida eScultura 400 2025
Road eBike with MAHLE ebikemotion 40Nm rear hub motor, 2 x 12 Shimano 105 drivetrain and carbon fork. In silhouette you would have no idea it was an eBike!
The silhouette of the bike would not give away the fact the eScultura benefits from a permanent tail wind. Cheating? Not when you're having this much fun. The eScultura 400 brings all the benefits of a pedal-assist motor to a serious road bike, delivering a way to keep up with the pack on the hills without a heavy, draggy feel when you're pedalling above the assistance limit. Shimano's benchmark 105 groupset and hydraulic disc brakes to deliver a ride that's as sporty as a regular bike. MAHLE's ebikemotion system uses a 40Nm rear hub motor powered by a fully integrated 250Wh battery hidden in the downtube. The low system weight combined with a carbon fork and sophisticated aluminium frame means the bike also feels lively even without power assistance. There is almost no drag at all from the motor when it is not engaged. The system has an iWoc button for controlling support levels and a sophisticated app provides an opportunity to adjust the riding feel as well as offering post-ride analysis features. The frame has mounts for mudguards and rack and a neat hidden kickstand mount. Cable routing is through the frame with cables entering through a specific headset cap to keep the cockpit nice and neat.
Highlights:
- Lightweight Triple butted aluminium frame
- MAHLE ebikemotion 40Nm hub motor
- Integrated 250Wh battery
- Carbon fork
- Shimano 105 2 x 12 drivetrain
- Shimano 105 hydraulic disc brakes
Specification
Frame
Lite - Hydroformed 6066 triple butted aluminium, integrated battery, mounts for mudguards, rack and kickstand. 9mm QR axle standard, BSA BB standard. Max. tyre size 700 x 45c without mudguards, 700 x 42c with mudguards. 27.5" x 47c
Motor
Mahle X30 Hub motor, 40Nm
Battery
Mahle ix250Wh Battery Pack
Battery Capacity
250Wh
Charger
Mahle X30 Charger
Mode Switch
Mahle iWoc ONE
Fork
Mission CX CF3; carbon. Max. tyre size: 700 x 42c
Shifters
Shimano 105
Front Derailleur
Shimano 105 R7100
Rear Derailleur
Shimano 105 R7100; GS
Bottom Bracket
Shimano BSA
Chain
Shimano M7100
Chainset
Shimano 105; R7100; 52-36 tooth chainset with 170 mm-XS/S/M, 175 mm-L/XL crank
Cassette
Shimano 105; 11-36 teeth; 12 speed
Brake Lever
Shimano 105
Front Brake
Shimano 105 R7100; 2 piston hydraulic disc brake with Shimano RT64 160mm rotor
Rear Brake
Shimano 105 R7100; 2 piston hydraulic disc brake with Shimano RT66 160mm rotor
Grip
Merida Expert
Handlebar
Merida Expert CW; aluminium; 400mm (XS/S), 420mm (M/L), 440mm (XL)
Stem
Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 80mm (XS), 90mm (S), 100mm (M), 110mm (L/XL)
Head Set
Merida 8158
Pedal
VP Components - VPE-893
Saddle
Merida Expert SL; V-mount;
Seat Post
Merida Expert CC; aluminium; 30.9mm diameter; in-line
Rims
Merida Expert SL; 17mm inner rim width; 22mm depth; aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Front Hub
Shimano HB-TC500; 100 x 12mm; 28 Spokes; Centerlock
Front Tyre
Maxxis Pursuer; 700 x 32C; Kevlar bead, folding
Rear Tyre
Maxxis Pursuer; 700 x 32C; Kevlar bead, folding
Colour
Red/Black
Season
2025
Front Light
CG-119PG
Rear Light
CG-404RG
The silhouette of the bike would not give away the fact the eScultura benefits from a permanent tail wind. Cheating? Not when you're having this much fun. The eScultura 400 brings all the benefits of a pedal-assist motor to a serious road bike, delivering a way to keep up with the pack on the hills without a heavy, draggy feel when you're pedalling above the assistance limit. Shimano's benchmark 105 groupset and hydraulic disc brakes to deliver a ride that's as sporty as a regular bike. MAHLE's ebikemotion system uses a 40Nm rear hub motor powered by a fully integrated 250Wh battery hidden in the downtube. The low system weight combined with a carbon fork and sophisticated aluminium frame means the bike also feels lively even without power assistance. There is almost no drag at all from the motor when it is not engaged. The system has an iWoc button for controlling support levels and a sophisticated app provides an opportunity to adjust the riding feel as well as offering post-ride analysis features. The frame has mounts for mudguards and rack and a neat hidden kickstand mount. Cable routing is through the frame with cables entering through a specific headset cap to keep the cockpit nice and neat.
Highlights:
- Lightweight Triple butted aluminium frame
- MAHLE ebikemotion 40Nm hub motor
- Integrated 250Wh battery
- Carbon fork
- Shimano 105 2 x 12 drivetrain
- Shimano 105 hydraulic disc brakes
Specification
Frame
Lite - Hydroformed 6066 triple butted aluminium, integrated battery, mounts for mudguards, rack and kickstand. 9mm QR axle standard, BSA BB standard. Max. tyre size 700 x 45c without mudguards, 700 x 42c with mudguards. 27.5" x 47c
Motor
Mahle X30 Hub motor, 40Nm
Battery
Mahle ix250Wh Battery Pack
Battery Capacity
250Wh
Charger
Mahle X30 Charger
Mode Switch
Mahle iWoc ONE
Fork
Mission CX CF3; carbon. Max. tyre size: 700 x 42c
Shifters
Shimano 105
Front Derailleur
Shimano 105 R7100
Rear Derailleur
Shimano 105 R7100; GS
Bottom Bracket
Shimano BSA
Chain
Shimano M7100
Chainset
Shimano 105; R7100; 52-36 tooth chainset with 170 mm-XS/S/M, 175 mm-L/XL crank
Cassette
Shimano 105; 11-36 teeth; 12 speed
Brake Lever
Shimano 105
Front Brake
Shimano 105 R7100; 2 piston hydraulic disc brake with Shimano RT64 160mm rotor
Rear Brake
Shimano 105 R7100; 2 piston hydraulic disc brake with Shimano RT66 160mm rotor
Grip
Merida Expert
Handlebar
Merida Expert CW; aluminium; 400mm (XS/S), 420mm (M/L), 440mm (XL)
Stem
Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 80mm (XS), 90mm (S), 100mm (M), 110mm (L/XL)
Head Set
Merida 8158
Pedal
VP Components - VPE-893
Saddle
Merida Expert SL; V-mount;
Seat Post
Merida Expert CC; aluminium; 30.9mm diameter; in-line
Rims
Merida Expert SL; 17mm inner rim width; 22mm depth; aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Front Hub
Shimano HB-TC500; 100 x 12mm; 28 Spokes; Centerlock
Front Tyre
Maxxis Pursuer; 700 x 32C; Kevlar bead, folding
Rear Tyre
Maxxis Pursuer; 700 x 32C; Kevlar bead, folding
Colour
Red/Black
Season
2025
Front Light
CG-119PG
Rear Light
CG-404RG
Model Year | 2025 |
---|---|
Options | XS (Warehouse stock allow 3-6 days for delivery) Red/Black Available S (Warehouse stock allow 3-6 days for delivery) Red/Black Available M (Warehouse stock allow 3-6 days for delivery) Red/Black Available L (Warehouse stock allow 3-6 days for delivery) Red/Black Available XL (Warehouse stock allow 3-6 days for delivery) Red/Black Available |
Wheel Size | 700 |
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
